Professional Series Bullet IP Cameras

Professional Series Bullet IP Cameras are high-performance surveillance cameras that are designed for outdoor use. These cameras are typically used in commercial, industrial, and government settings where high-quality surveillance is required.

Bullet IP cameras are named after their bullet-shaped housing, which is typically made of metal and is weatherproof to protect the camera from rain, snow, and dust. They are usually mounted on walls or ceilings and are equipped with infrared night vision to capture clear images in low-light conditions.

Professional Series IP Cameras

Professional Series IP Cameras

These cameras are also equipped with advanced features such as motion detection, two-way audio, and remote viewing capabilities. They use Power over Ethernet (PoE) technology to transmit data and power over a single Ethernet cable, which simplifies installation and reduces costs.

Professional Series Bullet IP Cameras can record and store video footage on an on-board SD card, on a network video recorder (NVR), or on cloud-based storage systems. They can also be integrated with other security systems such as alarms, access control systems, and video management software.

Overall, Professional Series Bullet IP Cameras are an excellent choice for anyone who wants to monitor and secure their property, whether it’s a large commercial building, an industrial facility, or a government institution.

The Matrix Professional Series IP Cameras are designed to deliver exceptional performance, especially in low-light conditions. These cameras feature top-quality components such as the Sony STARVIS sensor and high MTF lens, ensuring unparalleled image quality. Their True WDR algorithm enables consistent image quality even in changing lighting conditions. Furthermore, the built-in intelligent analytics, including Intrusion Detection and TripWire, provide real-time security.

With H.265 Compression and Automatic Motion-based Frame Rate Reduction, these cameras are designed to save up to 50% bandwidth and storage. Additionally, the new compact series of Matrix Professional Bullet IP Cameras are IK10 certified, ensuring resistance against vandalism.

These cameras are an ideal choice for a variety of applications, including Retail, BFSI, Transportation and Logistics, R&D Labs, Regional and Branch Offices, and more. With Matrix IP Video Surveillance, enterprises can ensure total security and peace of mind.

Matrix-SATATYA-IP-Cameras

Email us at in**@am*********.com or call us at 9315441078 , 9034757673 for Face Attendance Machine price and installation. Just give us try we will never let you down.

1.1.1      Surveillance system

A comprehensive and integrated plant security and surveillance system, including all necessary hardware, software, firmware, interfaces, and accessories, must be provided for the Office  utility. The bidder’s offering should encompass complete hardware and software, tailored to meet any additional requirements. The specifications aim to outline the functional and design prerequisites for the Perimeter Intruder Detection System and CCTV System, which will gather video information from various perimeter operation areas of the Office .

In order to enhance Office security and monitoring, it is recommended that a minimum of four cameras be installed in all Office oratories. However, the precise number of cameras required should be determined through a comprehensive survey that takes into account the specific needs and layout of each Office.

To ensure the preservation of recorded data, it is imperative that all camera recordings be stored in a local drive. This facilitates easy access to the footage within the Office premises itself. Moreover, provisions should be made to enable remote viewing of the camera feeds from off-site locations, such as a state office. This feature allows authorized personnel to monitor Office activities in real-time whenever necessary, even if they are not physically present.

To maintain a thorough record of events, it is advised that the DVR system be capable of storing a minimum of one month’s worth of footage. This duration ensures that a substantial amount of data is retained, enabling retrospective analysis of any incidents or investigations that may arise. By adhering to these guidelines, Office oratories can significantly enhance their security measures and improve overall monitoring capabilities.

The bidder is responsible for the selection, design, engineering, manufacturing, testing, installation, and commissioning of the system to the satisfaction of the purchaser. This tender also includes the provision of cables, cable trays, power packs, furniture, and erection hardware. The bidder must guarantee the satisfactory performance of the equipment under stipulated variations of voltage and frequency. The design and manufacture should ensure interchangeability of equipment/components of the same type and rating.

The CCTV system should include a digital video recording facility and a data management system located in a suitable independent location. The bidder is expected to provide a suitable Digital Video Recording & Management System (DVRMS) for this purpose, which comprises:

  1. Video Management system
  2. Network Video Recording (NVR) / Camera Servers
  3. suitable software
  4. Network-connected cameras and/or network-connected camera streamers
  5. Network infrastructure for Camera

Each alarm and camera within the system should allow individual configuration of the following settings:

Pre-Record Duration

The duration of pre-recorded video associated with an alarm/event, selectable from a list of values between 0 seconds and 5 minutes.

Post-Record Duration

The duration after an alarm/event that event-activated recordings will continue, selectable from a list of values between 0 seconds and 5 minutes.

Frame Rate

The desired video quality for event-activated recordings, with the ability to have different frame rates for user, event-activated, scheduled, and motion detection activated recordings. The selection should cover the entire range of frame rates supported for the camera/streamer.

Storage

Minimum 30 days storage capacity should be avaiOffice le in local DVR. The data must be keep safe and secure.

Retention Period

The default period for retaining event-activated recordings before deletion. The retention period of individual recordings should be changeable as needed, selectable from a list of values ranging between one hour and forever.

The maximum allowable limits for pre-record and post-record durations mentioned above should be configured on a camera-by-camera basis. However, each alarm or event that triggers video recording should also be individually configurable, with pre and post-alarm periods selected from a range defined by the maximum settings for the camera.

DVRMS systems that require a single pre and post record event period to be defined for all alarms and events on an individual camera, or for all alarms and events on all cameras, are not acceptable.

A CCTV system should incorporate the following essential functionalities

gCMOB/iCMOB Compatibility

The system must be designed to support the gCMOB/iCMOB application, which enables users to access and control live streaming from CP PLUS IP Cameras, DVRs/NVRs, and Video Door Phones. The application offers a user-friendly graphical user interface (GUI) and features such as up to 16 live viewing split-ups, InstaOn cloud support, playback, digital zoom, two-way talk, and more.

True Day/Night (ICR)

The CCTV cameras should employ True Day/Night functionality using an Infrared Cut Filter (ICR). This technology allows the camera to capture colour images during the day, and as the scene darkens, it automatically switches to monochrome mode by illuminating the scene with infrared light. This feature ensures visibility in low-light conditions.

Regions of Interest (ROI)

The system should include the capability to define and monitor specific areas of interest within the camera’s field of view. This allows operators to focus on critical regions while maintaining situational awareness of less important areas. ROI functionality enhances the effectiveness of surveillance and provides targeted monitoring.

By incorporating these functionalities into the CCTV system, it ensures users have access to live streaming, control over their surveillance devices, enhanced visibility in low-light conditions, and the ability to focus on important areas of interest while maintaining overall situational awareness.

Feature Specification
Image Sensor 1/3” 4MP Progressive scan CMOS (0.84667cm)
Effective Pixels 2560 (H) × 1440 (V)
Lens 3.6mm (2.8mm optional)
Lens Type Fixed-focal
Lens Mount M12
Iris Type Fixed
Close Focus Distance 3.6 mm: 1.4 m; 2.8 mm: 1 m
DORI Distance 3.6mm- 85.2m (Detect) 34.1 m (Observe) 17.0 m (Recognize) 8.5 m (Identify)
2.8mm- 68.0 m (Detect) 27.2 m (Observe) 13.6 m (Recognize) 6.8 m (Identify)
White Balance Auto/natural/street lamp/outdoor/manual/regional custom
Back Light Compensation BLC / HLC / DWDR
ICR Auto (ICR)/Color/B/W
ROI Supported (4 areas)
Video Compression H.265/Smart H.264+/H.264/ H.264B/ MJPEG (only supported by the sub stream)
Angle of View 3.6 mm: H: 76°; V: 40°; D: 92;
2.8 mm: H: 90°; V: 50°; D: 107°
Pan, Tilt, Rotation Pan: 0°–355° Tilt: 0°–78° Rotation: 0°–355°
Image Rotation 0°/180° (0° by default)
Resolution 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720)
IR Distance 30 M
IR Control Auto; Manual
Motion detection OFF/ON (4 areas, rectangular)
Abnormality detection Motion detection, video tampering, network disconnection, IP conflict, audio detection and
illegal access.
Alarm Event Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio
detection; security exception
Built in Mic Supported
Audio Compression G.711a; G.711Mu; G.726; PCM (G.711a by default)
Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; NTP; Multicast,
ONVIF (Profile S/Profile T); CGI; InstaOn Cloud; Genetec
Ethernet RJ-45 (10/100Base-T)
Cyber Security Configuration encryption; Trusted execution; Digest; Security logs; HTTPS; Trusted upgrade; WSSE; Trusted boot; Account lockout; Generation and importing of X.509 certification; Video encryption.
Storage FTP
SDK and API Supported
Mirror Function Supported
Browser IE, Chrome, Firefox
Weatherproof Standard IP56 or better
Storage Temperature (-40 °C)to +60 °C (–40 °F to +140 °F)
Operating Temperature (-40 °C )to +60 °C (–40 °F to +140 °F)
Humidity ≤95%
Power Source 12V DC/PoE (802.3af) or 100-230 AC

Figure 3 Basic Architecture (Typical for a Office )

   Local Storage (DVR)
Remote Viewer

By incorporating these functionalities into the CCTV system, it ensures users have access to live streaming, control over their surveillance devices, enhanced visibility in low-light conditions, and the ability to focus on important areas of interest while maintaining overall situational awareness.1.1.2      Biometric attendance system

The comprehensive biometric attendance system, including suitable client software for generating monthly attendance reports. The system should encompass the following specifications:

Finger Print & Face Recognition

The system should support both fingerprint and face recognition methods for accurate authentication of individuals. This dual functionality enhances security and flexibility in employee attendance tracking.

Sufficient User Capacity

The system should have a user capacity capable of storing minimum 200 face templates for the entire year. This ensures that all employee attendance records can be stored securely without any limitations.

Permanent Database AvaiOffice ility

The system should provide a reliable and permanent database to store attendance records. This ensures that attendance data is accessible and retained for future reference or analysis. Device vendor must provide the free Data base application , Also need to provide Webacess provision for Admin user(s).

Attendance Software

The system should include user-friendly attendance software capable of generating attendance reports on a daily, weekly, monthly, and yearly basis. This software should offer customizable reporting options and allow easy extraction of attendance data as required.

Power Backup Facility

Each biometric device must have a reliable power backup facility to ensure uninterrupted operation, even during power outages. This can be achieved through the inclusion of backup batteries or other suitable power backup mechanisms.

Storage Facility

The biometric attendance system should provide adequate storage capacity to store attendance records securely. The bidder should specify the storage capacity for the system, considering the anticipated number of employees and the duration of data retention.

Machine Provision and Maintenance

The provision of the biometric attendance machine as well as its maintenance for a period of two year. The maintenance should include regular visits by a technical person to the site for any repairs or assistance in operating the system until it is live.

By meeting these requirements, the comprehensive biometric attendance system with suitable client software for generating monthly attendance reports. Additionally, the system should include provisions for power backup and sufficient storage capacity to ensure reliable and efficient attendance tracking.
