 MATRIX COSEC ENROLL FINGERPRINT

MATRIX COSEC ENROLL FINGER

Features of Matrix COSEC Enroll Fingerprint
  • USB based enrollment station
  • Optical fingerprint sensor
  • Compact and elegant design

Best quality Fingerprint reader.

MATRIX COSEC ENROLL FINGERPRINT

ACCESS CONTROL ENROLMENT STATIONS



How to enroll User fingerprints through COSEC Enrollment Station?

TECHNICAL SPECIFICATIONS

COSEC ENROLL FINGER
Finger Print SensorOptical (Scratch free sensor surface)
Operating VoltageFeed from PC/Laptop through USB
Enrolment Time< 0.1 Seconds (Typical)
InterfaceUSB 2.0 High Speed/Full Speed and Plug and Play
Resolution500 / 256 DPI Gray
Template Size384 Bytes
Sensing Area16 x 18 mm
Image Size288 x 320 Pixels
Image qualityDisplay during Enrolment
Operating SystemMicrosoft Windows
CertificationCE, FCC, KCC, WHQL
Operating Temperature0°C to + 50°C
COSEC ENROLL PALM
Operating SystemMicrosoft Windows
Operating VoltageFeed from PC/Laptop through USB
InterfaceUSB 2.0 High Speed/Full Speed and Plug and Play
Operating Temperature0°C to +50°C (32°F to 122°F)
Humidity5% to 95% RH Non-condensing
Sensor TechnologyFujitsu Sensor
Scope of CaptureEntire Palm
Capturing Distance40 to 60mm (1.5″ to 2.3″)
EncryptionAES (Cryptography > 128 Bit)
FRR< 0.01%
FAR< 00008%
Drip ProofYes
