Intrusion Alarm System WIRELESS TEXECOM

Intrusion Alarm System WIRELESS

  • • Suitable for premium residential and small commercial applications
  • • Expandable to 48 zones with 4 partition areas
  • • Accepts up to 32 Ricochet enabled wireless devices – No wireless expander required
Intrusion Alarm System WIRELESS TEXECOM

Intrusion Alarm System WIRELESS TEXECOM

Premier Elite 48-W Live Front Wireless Panel (TXIGES0004)

Premier Elite 48-W Live Front Wireless Panel (TXIGES0004)

We will help you in choosing the best Intrusion Alarm System.

Premier Elite Compact PW-W Wireless PIR White (866MHz) TXIGBK0003

Premier Elite Compact PW-W Wireless PIR White (866MHz) TXIGBK0003

Intrusion Alarm System WIRELESS TEXECOM

TXIGES0010/TXIKIT0016 Premier Elite 48-W Live Front Wireless Panel (TXIGES0004)
– 4 on-board hardwired zones + 32 wireless zones
– Onboard Keypad with LCD
– 4 Areas/Partitions. 500 Event Logs
– Plug on PSTN/GSM module for alarm communication to CMS and user
– Plug on Com-IP module with Android/Ios Apps (smartphone control)
– Tough Polycarbonate Construction
– Remote Programming and Maintenance Software
Features of GSM Communicator (Internal) (TXICEG0005)
–  Alarm notification through Call (No voice) + SMS
–  Area and Zone Wise Alarms through SMS
–  Arm/Disarm/Bypass/Control Outputs through SMS
• Includes Premier Elite 48-W Live Front Wireless Panel (866MHz)
• One Wireless Magnetic Contact  TXIGBC0004
• One Wireless Pet Immune PIR TXIGBK0003
• One Premier Elite ComGSM (Internal) TXICEG0005 for GSM Connectivity
TXIGBK0003 Premier Elite Compact PW-W Wireless PIR White (866MHz)
• Wireless digital pet immune PIR with Ricochet mesh technology
• Pet Immunity Up to 35 Kgs
• Typical 2 to 3 Year Battery Life
• 12m volumetric coverage
• Digital temperature compensation
• Sealed optics
Replacement of TXIGBA0003
TXIGBB0003 IMPAQ PLUS-W White (866MHz)
– Vibration Sensor Cum Magnetic Contact, designed to detect, the vibrations caused by an intruder attempting to force an entry, or the opening of a door or window
should never be mounted on any metal surface (aluminium etc)
please contact tech support or texecom for an alternate solution with Optex wireless compatible sensors for aluminium/metal window door frames
TXIGHA0004 PREMIER ELITE MICRO CONTACT-W White (866MHz)
– Small size Wireless Magnetic Contact to detect the opening of a door/window
– LED clearly indicates the following device states:
o Green LED = Magnet Secure
o Red LED = Magnet Open
o Orange LED = Device Tamper
– Available in White, Brown and Gray Colors
Compatible with Premier Elite control panels, Premier control panels & Ricochet Expansion Packs
TXIGBC0004 IMPAQ CONTACT-W White (866MHz)
– Wireless Magnetic Contact to detect the opening of a door/window
– 2 additional inputs. These may be used for any N/C wired Sensor like Smoke detectors, Glass Break detectors, PA buttons etc. and utilise wireless signal transmission to the receiver.
– The in-built reed switch can be disabledIMPAQ CONTACT-W ADI INDIA
– Magnetic Contact Wireless
should never be mounted on any metal surface (aluminium etc)
please contact tech support or texecom for an alternate solution with Optex wireless compatible sensors for aluminium/metal window door frames
TXIGBN0003 Premier Elite OH-W
Optical and heat fire sensing multifunction detector
• Ricochet mesh technology for unmatched wireless range
• 85dB(A) built-in sounder
• Powered by 3 x AAA batteries (included)
• Remotely check – Battery, Health, Signal and Device Status on Ricochet Software
Manufactured in partnership with apollo
TXIGCC0012 Premier SmartKey Black ADI India
– Iconic Keyfob with Arm/Part Arm/Disarm/Panic with status indication LED’s

Ricochet enabled wireless devices protect residential properties with ease. The Premier Elite 48-W features a new Commission Mode* setup procedure which makes the installation process simple, reliable and fast.

The Ricochet wireless technology has been invented to provide reliable wireless communications in commercial environments. The Premier Elite 48-W features Signal Security™ and self-healing functions delivering unparalleled communications reliability.

Ricochet enabled wireless devices to receive and repeat wireless transmissions from other devices. The size, scalability, and range of the entire system are extended as wireless signaling is no longer limited by point-to-point communications.

Key Features Intrusion Alarm System WIRELESS TEXECOM

  • Maximum Number Of Zones 48
  • Maximum Number Of Wireless Zones 32
  • Number Of Wired Zones (Onboard) 4
  • 8 Zone Expanders (Wired) 3
  • Event Log Time & Date Stamped 500
  • SMS Text Messaging •
  • Plug On Digimodem/ISDN Digimodem •
  • Single Pole Zone Wiring •
  • Double Pole Wiring •
  • End Of Line Wiring •
  • Part Sets 3 PER AREA
  • Programmable Outputs (Control Panel) 10
  • Multi Format Communication Protocols •
  • Remote & Local Upload/Download •
  • Printer Output •
  • Conventional Fire Detector Compatible •
  • EN 50131-1 G2
  • EN 50131-3 G2

More speed. More flexibility. More choice. The Premier Elite 48-W is a wireless control panel suitable for a wide variety of security applications. Combining class-leading Premier Series control panel architecture with Ricochet mesh network wireless technology, the Premier Elite 48-W is compatible with Texecom’s entire range of peripheral devices.

Please feel free to contact us if you have any query.

Email us at info@ampletrails.com or call us at 9818390836 for pricing and installation of this machine.
