The foundation of the Aadhaar program is based on biometric and demographic data that is unique to each citizen. The attendance web portal will use the information entered in the biometric devices and will act as a centralized management information system (MIS) for attendance. Under the new attendance system, the employees would be able to mark their attendance using biometric reading devices in various government offices. It will facilitate employees mark their attendance at other central offices also which would help the government to track their movements. AmpleTrails is providing Aadhaar enabled biometric time and attendance machine.

We are the largest supplier of Aadhaar based Biometric Time Attendance Machine.

iTab XP – Aadhaar Enabled Android TAB

Details Information of UIDAI approved Aadhar Enabled Biometric Attendance device.

Biometric Attendance System based on Aadhaar Authentication.

Aadhaar based Biometric Attendance System i TAB xS Catalog

Aadhaar based Biometric Attendance System i TAB xS Catalog

Aadhaar based Biometric Attendance System i TAB xt Catalog

Aadhaar based Biometric Attendance System i TAB xt Catalog

Aadhaar Enabled biometric attendance system iTAB xE Catalog

Aadhaar Enabled biometric attendance system iTAB xE Catalog

Aadhaar Enabled Biometric Attendance System (AEBAS)

Tablet Specification: 1.0 GHz Processor, 512 MB RAM, Support GSM SIM, 4GB internal internal storage ,which is expandable upto 8GB, One Micro USB Port, front facing VGA camera, Internal speaker, 7” Capacitive Touch Screen with display resolution of 800 x 480 pixel, GSM SIM card slot, Battery backup Upto 120 minutes, SAR values within acceptable range, Separate charging cort – AC adapter with 230 V, 50Hz operation, Micro USB host cable connectivity, 2G/3G mobile applicable, Wi-FI – I EEE 802.11b/g/n, Android 4.2.2 operating system, and Full featured web browser.

Scanner Specification: Image Resolution – 508 DPI, Image size – 258 x 336 pixels, Platen size – 16.1mm x 18.2mm, Effective sensing area – 12.9mm x 16.8mm, Image gray scale – 256 levels(8-bit), Light source / Typical life time – LED / 60,000 hrs, Fingerprint capture speed – 0.5 to 1.2 Sec with Smart Capture, Interface – USB 1.1 full speed, USB 2.0 high speed, 5V DC supply voltage (Via USB), 150mA current consumption, 27 x 40 x 73mm dimensions (W x L x H), 100g weight, 1500mm
cable length, Operating Temperature: -20 to 65 C, Operating humidity – 90% or less RH, ANSI I NCI TS 378 standards supported, BioAPI, FI Ps 201, ISO/I EC 19794-2, I SO/I EC 19794-4, Compliance – FCC, CE, RoHS, FBI PI V Single Finger, STQC, Supported Operating Systems – Windows 7, Windows Server 2008 R2, Android. AmpleTrails is providing biometric time and attendance machine which is according to the required specifications. If you want to place an order or want to get more information contact us at 09034757673 WhatsApp 9315441053 or 09818390836

You can send email us at info@ampletrails.com

Parameter Specification required
Tablet PC Make & Model
Processor 2.1 GHz Dual Core or higher
RAM 1 GB or higher
Internal Memory 8 GB or above
External Memory Expandable through micro SD card up to 32GB
Ports Micro USB 2.0 with OTG support, Round Pin Power input
Ethernet LAN Port To support Ethernet based LAN for Internet connectivity.
Display 7” (- 0.1”/+0.4”) Capacitive Touch with Multi Touch Gestures
Display Resolution 800 x 480  Pixels or higher, 16 Million Colours
Wi-Fi 802.11/b/g/n
Blue Tooth Version 4.0
Inbuilt SIM Slot 3G/ 4 G, SIM Slot
Mifare Smart Card Option Device should have Buit in Smart Reader to store the last 8 Digit Addhar Number .
Cameras Front Facing Camera with VGA solution
Battery 3000 mAH Li-Ion Battery
OS Linux, Android Lollipop or latest versions of operating systems
Screen guard Standard Screen guard for the Tablet PC
Certifications For OEM : ISO 9001 : 2008,
General requirements 1. Application to be deployed on android tablet.
2. The Supplier has to provide all necessary technical support for
integration of their device drivers with the client software and
associated UIDAI attendance applications.



Finger Print Scanner Make & Model Morpho-Sagem
Single Finger Print Scanner STQC certified Single Finger-print Optical Scanner for Aadhar Authentication with driver software,
in-built template extractor software API/SDK for Android Lollipop or latest version OS.
Resolution: Minimum 500 DPI with 5% margin on the lower side
Capture mode Plain live scan capture
Image Acquisition Requirements As per Standards for UIDAI Applications.
Maximum Acquisition time
(Placement to Template) :
< 3 secs.
Capture mode Auto capture with built-in quality check (incorporates NIST quality considerations).
Capture area > 12mm x 18mm or higher
Connectivity2 Micro USB.
Device should have integrated with Micro USB cable to connect to the Tablet PC.
Operating temperature 0 – 500 C
Humidity 10 – 90% non-condensing
Standards 1. The Biometric device must be STQC approved.
2. The Biometric  device  must  be UIDAI enlisted to use  forAEBAS application.
3.  The Bidder shall provide all necessary technical support for interfacing  the integrated Biometric  Device  with  AEBAS server through the mobile application software of  NIC.
STQC certificate of the device must be enclosed to Technical Bid.
4. Device should be plug and play with any Android Operating Systems and  Application  Software without  need  of any additional Software/License.
Software API 1. Compliant with UIDAI Device Capture common API specification.
2. API/SDK for Android Lollipop and above.
3. Supplier shall provide all necessary technical support for integration of their device drivers with the attendance software and associated UIDAI applications.
Enclosure 1.  Tablet PC and Finger Print Scanner shall be fixed firmly in an enclosure made up of Unbreakable (Hard) Fiber enclosure.
2.  The enclosure should be durable and should be able to withstand rough daily operational usage.
4.  The tablet should be vertically oriented in the casing. This is important because the attendance Application to be deployed is designed to run in vertical mode only.
5.  The Finger Print Scanner should be ergonomically placed to support ease of usage for Biometric attendance in standing posture of the users.
6.  The enclosure should be designed to cover / hide the android task bar of the Tablet PC, to prevent misuse of any other functionality of the tablet.
7.  The enclosure should have provision to access the power / reset button of the Tablet PC.
Application The Integrated device should be compatible and integrated with attendance application software of NIC and confirmation to that effect shall be submitted along with the bid. If the same is not done already, the same shall be tested and a report to that effect shall be submitted along with the bid.
The Biometrics data captured at the device level should be encrypted and comply as per UIDAI standards.



Tablet SpecificationScanner SpecificationDownload
  • Processor – 1.0 GHz Processor
  • RAM – 512 MB
  • Support GSM SI M
  • Internal Storage – 4GB internal, Expandable storage Upto 8GB
  • USB Port – One Micro USB Port
  • Front-facing VGA Camera
  • Internal Speaker
  • 7” Capacitive Touch Screen – Display Resolution 800 x 480 pixel
  • GSM SI M Card Slot
  • Battery backup Upto 120 minutes
  • SAR values within acceptable range
  • Separate Charging Port – AC adapter with 230 V, 50Hz Operation
  • Micro USB host cable connectivity
  • 2G/3G mobile applicable
  • Wi-FI – I EEE 802.11b/g/n
  • Android 4.2.2 operating system
  • Full featured web browser
  • Image Resolution – 508 DPI
  • Image Size – 258 x 336 Pixels
  • Platen Size – 16.1mm x 18.2mm
  • Effective Sensing area – 12.9mm x 16.8mm
  • Image Grayscale – 256 levels(8-bit)
  • Light Source / Typical life time – LED / 60,000 hrs
  • Fingerprint Capture Speed – 0.5 to 1.2 Sec with Smart Capture
  • Interface – USB 1.1 Full Speed, USB 2.0 High Speed
  • Supply Voltage – 5V DC (Via USB)
  • Current Consumption – 150mA
  • Dimensions (W x L x H) – 27 x 40 x 73mm
  • Weight – 100g
  • Cable length – 1500mm
  • Operating Temperature: -20 to 65 C
  • Operating Humidity – 90% or less RH
  • Supported Standards – ANSI I NCI TS 378, BioAPI, FI Ps 201,
  • I SO/I EC 19794-2, I SO/I EC 19794-4
  • Compliance – FCC, CE, RoHS, FBI PI V Single Finger, STQC
  • Supported Operating Systems – Windows 7, Windows Server 2008 R2, Android

Aadhaar Enabled Biometric Attendance System (AEBAS), Fingerprint

Download

Aadhaar based Biometric Attendance System Suppliers

WINDOWS RD SERVICE ENABLED AEBAS CLIENT APPLICATION:
(Note: For Windows 7 and above)
WINDOWS RD SERVICES INCLUDING DRIVERS FOR SELECTED DEVICES:
  • ACCESS COMPUTECH (Model – Startek FM220 – ACPL): – Download (30.0 MB)
  • SECUGEN CORPORATION (Model – HAMSTER PRO 20): – Download (3.0 MB)
  • IRITECH INC. (Model – IriShield-USB): – Download (10.6 MB)
  • MANTRA SOFTECH (Model – MFS100): – Download (19.6 MB)
ANDROID RD SERVICE ENABLED AEBAS CLINET APPLICATION:
(Note: For Android v4.4  and above)
  1. AEBAS Android Client APK Version 4.0: – Download (3.51 MB)
  2. Installation guide: – Download (2.46 MB)

For more information contact us at 09818390836, 09034757673 WhatsApp 9315441053 or email us at info@ampletrails.com.
