Multi Door IP Access Control Panel. Matrix COSEC ARC DC200P is a multi-door IP based access control panel with Wi-Fi or PoE+
2-Door Controller with PoE+, Wi-Fi, and Bluetooth
2-Door Controller with PoE+, Wi-Fi and Bluetooth
- Secured Socket Layer Enabled
- Works in Two Operation Modes:
- Standalone Mode with Built-in Software in COSEC PANEL LITE
- Network Mode with COSEC CENTRA with or without COSEC PANEL LITE
- Built-In PoE+ to Give Power to Readers and Lock (Check Lock Specifications) & Bluetooth
- Connect Third Party Wiegand Readers
- 50,000 Users and 5,00,000 Events Storage
- Connect Two Locks, Two Exit Switches(Panel Door Mode), Two Wiegand and/or RS-485 Readers
- Industry Standard Din Rail Mounting and Wall Mounting Options
COSEC ARC DC200P
- Secured Socket Layer Enabled
- Works in Two Operation Modes:
- Standalone Mode with Built-in Software in COSEC PANEL LITE
- Network Mode with COSEC CENTRA with or without COSEC PANEL LITE
- Built-In PoE+ to Give Power to Readers and Lock (Check Lock Specifications), Bluetooth Supported
- Connect Third Party Wiegand Readers
- 50,000 Users and 5,00,000 Events Storage
- Connect Two Locks, Two Exit Switches(Panel Door Mode), Two Wiegand and/or RS-485 Readers
- Industry Standard Din Rail Mounting and Wall Mounting Options
| GENERAL | |
| Maximum Readers | Up to 2 Readers (Wiegand and/or RS-485) |
| Maximum Doors | 2 |
| Maximum Users | 50,000 |
| Event Buffer | 500,000 |
| COMMUNICATION | |
| Ethernet | Yes, 10/100 Mbps |
| RS-485 | Yes |
| SSL Enabled | Yes |
| Bluetooth | Yes (BLE-10m) |
| Wi-Fi | Yes |
| PoE+ | Yes, IEEE 802.3 af/at |
| OPERATION MODES | |
| Direct Door Mode | With COSEC CENTRA (with COSEC PANEL LITE V2 for Dual Door Mode) |
| Panel Door Mode | With COSEC PANEL |
| READERS | |
| Reader Power Output | Max. 12V DC @ 0.250A |
| Reader Types | 2 Reader Port for any Wiegand or Matrix Reader |
| Interface | RS-485 (For Matrix Reader Only) and Wiegand IN |
| IN/OUT PORTS | |
| Exit Switch Port | Yes |
| Door Status Sense | Programmable NO, NC |
| Door Lock Relay | Maximum 30 V DC @ 2A, Relay SPDT, Form C |
| Door Lock Power | 12V DC @ 0.5A |
| AUX-IN Port | Yes |
| AUX-Out Port | 30V DC @ 2A, Relay SPDT, Form C |
| AUDIO-VISUAL | |
| LED | Yes (Tri Color) |
| ELECTRICAL | |
| Input Power | PoE+ (IEEE 802.3 af),12VDC @ 1.8A OR 12 VDC @ 2A Power Adaptor |
| CPU | ARM Processor, 800MHz |
| Memory | 256MB Flash, 2GB RAM |
| PHYSICAL | |
| Mounting | Wall Mount OR Din-Rail Mounting Options |
| Dimensions (W x H x D) (mm3) | 140mm(H) x 78mm(W) x 25mm(D) |
| Weight (kg) | 0.45 (0.99 lbs.) |
| ENVIRONMENTAL | |
| Humidity | 5% to 85% RH Non-Condensing |
| Operating Temperature | -10°C to + 50°C (32°F to 122°F) |
| OTHERS | |
| System Integration | API for Software Integration |
| CERTIFICATIONS | |
| CE, FCC, RoHS and UL | |
| *Due to continuous technology upgradations, product specifications are subject to change without notice. | |
