Matrix COSEC PATH DCCE

Card-Based Access Control and Time-Attendance Door Controller

[su_list icon=”icon: check”]

• EM Prox Card and Mobile Phone(BLE)
• Ethernet, PoE, Wi-Fi and BLE
• Door Lock, Door Sense, Exit Reader, Exit Switch, RS-485/RS-232, Wiegand IN/OUT
• IP65 Rated Controller with Built-in Readers
• 50,000 Users and 5,00,000 Events
• Tri-color LED and Buzzer
• 12VDC Power Supply through Adaptor or Battery Backup

[/su_list]

EM Proximity Card based Door Controller

BLE and EM Proximity Card Reader
Access Control and Time-Attendance
IP65 Rating
5,00,000 Events
Wi-Fi, BLE, Ethernet, RS-485/RS-232, POE
Built-In Door Lock Port, Door Sense Port, Exit Reader Port, Exit Switch Port, RS-485 and Ethernet Interfaces
Tri-color LED and Buzzer
12VDC Power Supply through Adaptor or Battery Backup

Matrix COSEC PATH DCCE

Name: Matrix COSEC PATH DCCE
Brand: Matrix
SKU: 21953
Price: 9792.00 INR
Availability: InStock

Biometric Door Controller — BLE, RFID, Wi-Fi, PoE, IP65

A compact, weatherproof door controller engineered for extreme conditions — supporting BLE and RFID Card credentials with Wi-Fi, Ethernet, and PoE connectivity. Ideal for Time-Attendance, Access Control, and Cafeteria Management across indoor and outdoor applications.

Get a Quote →
📞 Call: 9315441078

50,000Max users

500,000Event buffer

IP65Weather protection

PoEPower over Ethernet

Overview

Features of Matrix COSEC PATH DCCE

Matrix COSEC PATH DCCE Biometric Door Controller — Matrix COSEC PATH Series — Biometric Door Controller

The COSEC PATH Series — biometric door controllers — are the brain of the access control system, allowing only authorized users to enter premises and registering their entry and exit time. Specifically, Matrix COSEC PATH is a series of compact door controllers engineered to endure extreme weather conditions.

Furthermore, these controllers support credentials such as BLE and RFID cards, providing a dual advantage of advanced security. With versatile interfaces and PoE connectivity, they are best suited for both indoor and outdoor applications. In particular, advanced features like Wi-Fi, Bluetooth connectivity, PoE, IP65, and multi-credential support allow the system to fulfil the requirements of many organizations across diverse environments.

With a storage capacity of 500,000 events and 50,000 users, the COSEC PATH DCCE assures reliable and long-term consistent performance. Consequently, its IP65 design makes it a foolproof solution for Time-Attendance, Access Control, Cafeteria Management, and other applications.

COSEC PATH Variants

COSEC PATH DCFx

COSEC PATH DCCx

Specifications

COSEC PATH DCCE — Technical Specifications

The following specifications detail the full capabilities of the Matrix COSEC PATH DCCE. Specifically, the device is certified to BIS (IS 13252), CE, FCC, IEC 60950-1, and RoHS standards — additionally making it compliant for enterprise deployment across India and international markets.

General & Capacity

Specifically, the COSEC PATH DCCE supports BLE and RFID credentials with an IP65 rating — consequently making it suitable for demanding indoor and outdoor environments.

Parameter	Value
Credential Support	BLE and RFID Card
IP Rating	IP65 Design
RF Option	Proximity (EM Prox — 125KHz)
Max. Users	50,000
Event Buffer	500,000
Cards per User	Up to 2

Communication

Furthermore, the device supports multiple communication protocols — Wi-Fi, Ethernet, RS-232, RS-485, PoE, and Wiegand — providing flexible connectivity options for any installation.

Parameter	Value
Wi-Fi	Yes (IEEE 802.11 b/g/n)
Ethernet	Yes (10/100 Mbps)
RS-232 and RS-485	Yes
PoE	Yes (IEEE 802.3af)
Wiegand	Wiegand IN/OUT Available

Interface

Additionally, the interface covers door lock relay, exit switch, and door status sensing — as a result enabling complete door control from a single compact unit.

Parameter	Value
Exit Switch	Yes
Door Status Sense	Yes (2 States)
Door Lock Relay	30V DC @ 1A, Form C, SPDT Relay
Door Lock Power	Internal 12VDC @ 0.5A or External
Exit Switch Port	Yes

Hardware & Physical

Moreover, the hardware runs on a Cortex A8 800 MHz processor with 512 MB flash and 512 MB RAM — notably providing sufficient processing power for real-time access control decisions.

Parameter	Value
CPU	Cortex A8 800 MHz
Flash Memory	512 MB
RAM Memory	512 MB
LED	Single Tri-Color LED
Buzzer	Yes
Tamper Detection	Yes
Operating Temperature	0°C to +50°C (32°F to 122°F)
Humidity	5% to 95% RH Non-Condensing
Power Supply	12V DC @ 2A
Power to Door Lock	12V DC @ 0.5A (Adapter Mode) / 30V DC @ 1A (PoE Mode)
Dimensions (W × H × D)	50.5 × 137 × 34 mm (1.98″ × 5.39″ × 1.33″)
Weight	0.18 kg (0.39 lbs)
Certifications	BIS (IS 13252), IP65, CE, FCC, IEC 60950-1, RoHS

Compatibility

In addition, the device offers API integration for software connectivity. It supports two operational modes — Direct Door with COSEC CENTRA Server and Panel Door with COSEC PANEL LITE V2.

Parameter	Value
System Integration	API for Software Integration
Operational Modes	Direct Door with COSEC CENTRA Server Panel — Door with COSEC PANEL LITE V2

Applications

COSEC PATH DCCE — Applications

The Matrix COSEC PATH DCCE is specifically designed for a wide range of physical security applications. Furthermore, its IP65 weatherproof rating makes it equally suitable for both indoor and outdoor deployments — consequently making it a versatile choice across industries.

🔐 Access Control

⏱️ Time-Attendance

👷 Contract Workers Management

📊 Job Processing and Costing

Download

COSEC PATH DCCE — Technical Datasheet

Additionally, download the complete technical datasheet to review all specifications and certifications before placing your order. In addition, visit the official Matrix technical specifications page for detailed integration documentation.
