Features of COSEC DOOR FOT V4
Matrix Biometric Attendance
COSEC Door FOT
Optical Fingerprint and Card-Based Time-Attendance Terminal
COSEC door controllers are the front-end terminals that people use during entry and exit. Door controllers read biometric credentials – fingerprint and palm vein or RFID cards to log each entry/exit and control door locks. Door controllers are connected with the COSEC or site controller. These automatic door controllers can monitor and control additional readers, doors, and auxiliary input and output ports. They store all user access information and send entry-exit details to the COSEC in real-time.
Featuring Ethernet, Wi-Fi, and 3G/4G connectivity, COSEC door controllers offer extra flexibility in designing a security solution while reducing installation and maintenance costs. These advanced door controllers have multi-functional supervised auxiliary input and output ports to control various applications. Input devices such as motion detectors, fire alarm panels, video surveillance, etc. and external devices like video recorders, siren, etc. can be connected to these ports.
Modules such as Time-Attendance, Access Control, Cafeteria Management, Visitor Management, Visitor Management, Contract Workers Management, and Field Visit Management are supported by these door controllers. Hence, COSEC door controllers are futuristic and versatile devices designed for reliability, modularity, and high performance.
COSEC VARIANTS
- ARGO Series
- VEGA Series
- DOOR Series
- PATH Series
- ARC Series
COSEC DOOR FOT V4
| GENERAL | |
| Credential Support | Fingerprint, RFID Card and PIN |
|
RF Option |
Proximity (EM Prox, HID Prox)
(COSEC CPM Module Required) |
| CAPACITY | |
| Max. Users | 50,000 |
| Max. Template Storage | 9,600 in 1: N Mode and 100,000 in 1:1 Mode |
| Event Buffer | 500,000 |
| Templates per User | Up to 10 (Single Template per Finger Mode)
Up to 5 (Dual Template per Finger Mode) |
| Cards per User | Up to 2 |
| COMMUNICATION | |
| Ethernet | Yes (10/100 Mbps) |
| Mobile Broadband | Yes |
| USB | 2 USB Port (Data Transfer and 2G-3G Dongle) |
| HARDWARE | |
| CPU | 400 MHz ARM 9 Based Processor |
| Memory | 256 MB Flash + 128 MB DDR3 RAM |
| Display | 128 x 64 Dot Matrix Display |
| Display Size | 38.1mm x 60.96mm (1.5” x 2.4”) |
| Buzzer | Yes |
| Keypad | 16 Touch Sense Keys |
| Operating Temperature | 0°C to +45°C (32°F to 113°F) |
| Humidity | 5% to 85% RH Non – Condensing |
| Tamper Detection | Yes |
| Power | 12V DC @ 2A |
| Power to Door Lock | 12V DC @ 0.5A (Power to Lock from COSEC DOOR FOT)
30V DC @1 A (Power to lock from External Adaptor) |
| Dimensions (W x H x D) | 100mm x 220mm x 56mm (3.93″x 8.66″x 2.20″) |
| Weight | 0.65 Kgs (1.43 lbs.) |
| COMPATBILITY | |
| System Integration | API for Software Integration |
| Operational Modes | Direct Door with COSEC CENTRA Server Panel Door with COSEC PANEL LITE V2 |
| SENSOR | |
| Sensor Name | Suprema Sensor |
| Sensor Technology | Optical Sensing |
| Encryption | 256-bit AES |
| Water-proof | Yes |
| False Acceptance Ratio (FAR) | 0.001% |
| False Rejection Ratio (FRR) | 0.01% |
| Resolution (dpi) | 500 dpi |
| Sensing Area | 16.0mm x 19.0mm |
| Template Size | 256 ? 384 bytes (Configurable, 384 bytes default) |
| Image Size (Pixel) | 272mm x 320mm |
APPLICATIONS
- Access Control
- Time-Attendance
- Visitor Management
- Contract Workers’ Management
- Cafeteria Management
- Job Processing and Costing
If you want to get more details please fill the form below. Our experts will contact you to give face attendance and various other solutions as per your requirements. Call us at 9315441078 or email us at in**@am*********.com
