SATATYA MIDR20FL36CWS Matrix CCTV
Original price was: ₹ 8,000.00.₹ 5,856.00Current price is: ₹ 5,856.00.
2MP IR Dome Camera (3.6mm Lens)
- 1 / 2.8” SONY – CMOS (Exmor Technology – STARVIS Series)
- 2MP, 0Lux with IR LED ON
- Horizontal Field of View: 90 degrees
- IR Range of up to 30 meters
- Video Analytics: Trip Wire, Intrusion Detection and Motion Detection
- 265/H.264/MJPEG Video Compression
- PoE Support, NAS Storage, SD Card(512GB), Quad Stream Support
- True WDR, 3D Noise Reduction, Adaptive Streaming, Smart Streaming and ROI, SNR > 70 dB
IK10, IP66, BIS, CE, FCC and RoHS
Features of SATATYA MIDR20FL36CWS
- SONY STARVIS Sensor
- H.265 Compression
- True WDR (120dB)
- Smart Streaming and Adaptive Streaming
- On-board storage (512GB)
- High Signal-to-Noise Ratio (>70dB)
Matrix Professional Series Dome IP Cameras are built using superior components such as Sony STARVIS sensor and higher MTF
lens to offer unmatched image quality, especially during the low light conditions. Powered by the True WDR algorithm, these cameras
offer consistent image quality even in highly varying lighting conditions. Built-in intelligent analytics including Intrusion Detection,
Trip Wire, etc. ensure real-time security. Moreover, H.265 compression and Automatic Motion based Frame Rate Reduction save
bandwidth and storage up to 50%
AmpleTrails 2mp-ir-dome-fixed-3dot6mm-lens
[su_button url=”https://ampletrails.com/wp-content//uploads/2020/10/AmpleTrails-2mp-ir-dome-fixed-3dot6mm-lens.pdf” target=”blank” style=”soft” center=”yes” icon=”icon: envelope-o” text_shadow=”0px 0px 0px #000000″ desc=”Datasheet of 2MP IR Dome Fixed 3.6mm Lens”] SATATYA MIDR20FL36CWS Matrix IP Camera[/su_button]
SATATYA-MIDR20FL36CWS-Matrix-2MP-IP-Camera-NVR-scaled
Details about SATATYA MIDR20FL36CWS
[su_table]
| TECHNICAL SPECIFICATIONS of SATATYA MIDR20FL36CWS | |
| IMAGE SENSOR | |
| Resolution | 2 MP (1920 x 1080) |
|
Sensor Type and Size |
1/2.8″ SONY – CMOS 2MP Active Pixel
Progressive Scan, Back Illuminated Image sensor (EXMOR Technology – STARVIS Series) |
| LENS | |
|
Minimum Illumination |
Colour – 0.01 Lux @ F1.2 (AGC ON)
Monochrome – 0 Lux |
| Focal Length | 3.6mm |
| Focus Range | 0.3m to infinity |
|
Field of View (FOV) |
HFOV – 90°
VFOV – 47° DFOV – 110° |
| Lens Mount | M12 |
| Focus | Fixed focus |
| Aperture (F#) | F 1.2 |
| Iris Type | Fixed |
| IR Range | 30m |
| IR Led Wavelength | 850nm |
| IR Switching | Auto/ Manual |
| HARDWARE SPECIFICATIONS | |
| SD Card | Up to 512GB |
| Camera Adjustment Angle | Pan: 0° to 360°
Tilt: 0° to 75° Rotation: 0° to 360° |
| IMAGE AND VIDEO | |
| No of Stream Profiles | 4 |
|
Stream Profiles |
Profile 1: 1080p(2MP)/720p/D1/2CIF/CIF/QCIF up to 30 fps (H.265/ H.264)
Profile 2: D1/2CIF/CIF/QCIF up to 30fps (H.265/H.264) Profile 3: 1080p(2MP)/720p/D1/2CIF/CIF/QCIF up to 5 fps (MJPEG) Profile 4: 720p/D1/2CIF/CIF/QCIF up to 30 fps (H.265/H.264/MJPEG) |
| Available Resolutions | 1920 x 1080, 720p, D1, 2CIF, CIF, QCIF |
| Max Resolution | 1920 x 1080 |
| Bitrate | 128 kbps-8Mbps |
| Bitrate Type | CBR, VBR |
| Video Compression | H.265, H.264, MJPEG |
| Frame Rate | 1-30fps |
[/su_table]
Call us at 9315441078. By filling the below form, you can get in touch with our experts for your query related to Matrix IP cameras. Email us at in**@*********ls.com
