COSEC DOOR FOP

cosec door fop

Matrix COSEC DOOR FOP, one of the variants of Door Access Control systems, is designed to give organizations top of the line security for their infrastructure and employees. With its advanced features, along with biometric credentials (fingerprints/palm veins), PIN and RFID card based access, the device offers foolproof security solutions for organizations in all industries. Its award-winning design, multiple credentials and connectivity options fulfill the requirements of all types of businesses. Therefore, this solution is ideal for various sectors that include Hospitals, Schools, Banks, Government Institutes, Hotels, Remote Sites and Large/Small Enterprises.

COSEC DOOR FOP, a conventional Door Controller, can be used for various applications like Access Control, Time-Attendance, Visitor Management, Cafeteria Management, Vehicle Access Management and Contract Workers Management. COSEC DOOR FOP is a door controller, which has 128*64 Dot Matrix Display with touch sense keypad. It is capable of storing up to 9,600 fingerprint templates and 5,00,000 events. Moreover, with Ethernet, Wi-Fi and 3G/4G connectivity, this device offers extra flexibility in designing a security solution while reducing installation and maintenance costs. This RFID card based or fingerprint door entry system can work in a network or a standalone mode. It offers various interfaces like exit reader, exit switch, auxiliary input/output port and USB port.

Hence, high quality biometric fingerprint door access systems such as this, with built-in controllers are versatile devices designed for reliability, modularity and performance.

APPLICATIONS
Time- attendanceTime AttendanceAccess ControlAccess Control
Visitor managementVisitor Managementcafeteria managementCafeteria Management
contract workers managementContract Workers Management
KEY FEATURES

superior designSuperior Design

  • If Design, Good Design and India Design Mark Awards
  • 128×64 LCD Display
  • Touch Sense Keypad
  • Audio Visual Indications

saves timeSaves Time by Quick Fingerprint Identification

  • Identification in Less than One Second
  • 1:1 and 1:N Verification

manage usersManage many Users from a Device

  • 5,00,000 Events Storage
  • 9,600 Fingerprint Templates

select credentials as per requirementsSelect Credential as per Requirement

  • Fingerprint, RFID Card and PIN
  • Proximity and Smart Cards
  • EM Prox, HID Prox, Mifare and HID iCLASS

connect devicesConnect Device with Server using available Option

  • Wired and Wireless Connectivity
  • Ethernet and RS-485
  • Mobile Broadband (3G/4G) via USB

perform functionsPerform Functions Faster from the Device itself

  • User Enrolment from Device
  • Perform Attendance Functions
  • Take Out the Event Data via USB

various interfacesVarious Interfaces to Control Various Applications

  • Door Relay and Door Sense
  • Auxiliary Input and Output Ports
  • Exit Reader and Exit Switch

multi door softwareMulti-door Access Control Software

  • Compatible and Centralized Solution for Multiple locations Enterprises
  • Minimal Wiring
  • Standalone and Network based Access Control

INTERFACE DIAGRAM
cosec door fop
TECHNICAL SPECIFICATION COSEC DOOR FOP
VariantsCOSEC DOOR FOPCOSEC DOOR FOPQ
Credential SupportFinger, Card and PINFinger, Card and PIN
Display128 x 64 Dot Matrix Display128 x 64 Dot Matrix Display
Keypad16 Touch Sense Keys16 Touch Sense Keys
User Capacity50,000 (Max. 9600 in 1:N Mode)50,000 (Max. 9600 in 1:N Mode)
Template Per UserUp to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode)Up to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode)
Template Storage Capacity9600 in 1:N Mode and 1 lac in 1:1 Mode9600 in 1:N Mode and 1 lac in 1:1 Mode
Cards Per UserUp to TwoUp to Two
Event Buffer5,00,0005,00,000
Types of Cards SupportProximity Card (EM Prox and HID Prox) and Smart Card (Mifare and HID iCLASS) (Card Module Required)Proximity Card (EM Prox and HID Prox) and Smart Card (Mifare and HID iCLASS) (Card Module Required)
Mobile BroadbandYes (2G/3G Support)Yes (2G/3G Support)
RS-485Yes (115.2 Kbps)Yes (115.2 Kbps)
EthernetYes (10/100 Mbps on Ethernet)Yes (10/100 Mbps on Ethernet)
Exit SwitchYesYes
Door Status SenseProgrammable NO, NC and SupervisedProgrammable NO, NC and Supervised
Door Lock RelayForm C, SPDT Relay (Max 2A@30 VDC)Form C, SPDT Relay (Max 2A@30 VDC)
Door Lock PowerInternal 12VDC @ 0.5A or ExternalInternal 12VDC @ 0.5A or External
Aux-INProgrammable NO, NC and SupervisedProgrammable NO, NC and Supervised
Aux-OUTForm C, SPDT Relay (Max 2A @ 30VDC)Form C, SPDT Relay (Max 2A @ 30VDC)
Reader Interface typesRS-232, and Wiegand IN onlyRS-232, and Wiegand IN only
Reader Types1 Port for Card Reader/Finger Reader/Card Finger Combo Reader/Third Party Wiegand reader1 Port for Card Reader/Finger Reader/Card Finger Combo Reader/Third Party Wiegand reader
USB2 USB Ports (1 for Data Transfer and 1 for 2G-3G Dongle)2 USB Ports (1 for Data Transfer and 1 for 2G-3G Dongle)
BuzzerYesYes
LED4 LEDs (Status, Alarm, Allowed, Denied)4 LEDs (Status, Alarm, Allowed, Denied)
CPU400 MHz ARM 9 based Processor400 MHz ARM 9 based Processor
Flash Memory256MB Flash256MB Flash
RAM Memory128MB DDR2128MB DDR2
Input Power12VDC @ 2A12VDC @ 2A
Reader Power OutputInternal 12 VDC @ 0.5 A or ExternalExternal Internal 12 VDC @ 0.5 A or External
Battery BackupNoNo
Humidity5% to 85% RH Non-condensing5% to 85% RH Noncondensing
Operating Temperature0°C to + 50°C (32°F to 122°F)0°C to + 50°C (32°F to 122°F)
Tamper DetectionYesYes
CertificationCE and RoHSCE and RoHS
STQCNoVerified
Dimension (mm)100X220X56100X220X56
Weight (kgs)0.650.65
Get the COSEC DOOR FOP Fingerprint Access Control System for your organization. For more information fill the following form contact us at 91-9315-4410-53, +91-9315-4410-78WhatsApp 9315441053 or email us at info@ampletrails.com.

read more

COSEC DOOR FOT

cosec door fot

APPLICATIONS
Time- attendanceTime-Attendancecafeteria managementCafeteria Management
KEY FEATURES
superior design MATRIX
Superior Design
  • If Design, Good Design and India Design Mark Awards
  • 128×64 LCD Display
  • Touch Sense Keypad
  • Audio Visual Indications
saves time MATRIX
Saves Time by Quick Fingerprint Identification

  • Identification in Less than One Second
  • 1:1 and 1:N Verification

higher capacity MATRIXManage Multiple users from a Device

  • Events Storage up to 5,00,000
  • 9,600 Fingerprint Templates

select credentials as per requirements
Select Credential as per Requirement

  • Fingerprint, RFID Card and PIN
  • Proximity Cards
  • EM Prox and HID Prox Cards

perform functions
Perform Functions Faster from the Device itself

  • User Enrolment from Device
  • Perform Attendance Functions
  • Take Out the Event Data via USB

perform functions
Perform Applications using APIs

  • Communication with Third Party Software
  • Integration using Device API
  • Device and User Configuration, Enrollment, Transfer of Commands and Events

convenient operation
Convenient Operation and Installation

  • User Friendly UI
  • Standalone and Network Operation
  • Easy Mounting on a Back Plate
  • Leverage Existing Network Infrastructure
  • Minimum Wiring

INTERFACE DIAGRAM

TECHNICAL SPECIFICATIONS COSEC DOOR FOT
VariantsCOSEC DOOR FOTCOSEC DOOR FOTQ
Credential SupportFinger, RFID Card and PINFinger, RFID Card and PIN
Display128 x 64 Dot Matrix Display128 x 64 Dot Matrix Display
Keypad16 Touch Sense Keys16 Touch Sense Keys
User Capacity50,000 (Max. 9600 in 1:N Mode)50,000 (Max. 9600 in 1:N Mode)
Template Per UserUp to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode)Up to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode)
Template Storage Capacity9600 in 1:N Mode and 1 lac in 1:1 Mode9600 in 1:N Mode and 1 lac in 1:1 Mode
Cards Per UserUp to TwoUp to Two
Event Buffer5,00,0005,00,000
Types of Cards SupportProximity Card (EM Prox and HID Prox)Proximity Card (EM Prox and HID Prox)
Mobile BroadbandYes (3G/4G Support)Yes (3G/4G Support)
RS-485Yes (115.2 Kbps)Yes (115.2 Kbps)
EthernetYes (10/100 Mbps on Ethernet)Yes (10/100 Mbps on Ethernet)
USB2 USB Ports (1 for Data Transfer and 1 for 3G-4G Dongle)2 USB Ports (1 for Data Transfer and 1 for 3G-4G Dongle)
BuzzerYesYes
LED4 LEDs (Status, Alarm, Allowed, Denied)4 LEDs (Status, Alarm, Allowed, Denied)
CPU400 MHz ARM 9 based Processor400 MHz ARM 9 based Processor
Flash Memory256MB Flash256MB Flash
RAM Memory128MB DDR2128MB DDR2
Input Power12VDC @ 2A12VDC @ 2A
Battery BackupNoNo
Humidity5% to 85% RH Non-condensing5% to 85% RH Noncondensing
Operating Temperature0°C to + 50°C (32°F to 122°F)0°C to + 50°C (32°F to 122°F)
Tamper DetectionYesYes
CertificationCE and RoHSCE and RoHS
IP65VerifiedVerified
STQC CertifiedNoVerified
Dimension (mm)100X220X56100X220X56
Weight (kgs)0.650.65
Get the COSEC DOOR FOT Time Attendance System for your organization. For more information fill the following form contact us at 91-9315-4410-53, +91-9315-4410-78WhatsApp 9315441053 or email us at info@ampletrails.com.

People found us through search:

read more

COSEC PATH DCCX

TIME ATTENDANCE & ACCESS CONTROL WITH PROXIMITY & SMART CARDS

cosec path dccx
Technical Specifications

APPLICATIONS
Time- attendanceTime AttendanceAccess ControlAccess Control
Visitor managementVisitor Managementcontract workers managementContract Workers Management
KEY FEATURES
superior design MATRIX
Superior Design

  • Compact Design
  • IP65 Rating
  • Tri Colour LED (Allowed, Denied/Alarm and Status)

manage users MATRIXBetter Capacity to Manage Multiple Users and Events

  • 50,000 Events Storage Capacity
  • 2,000 Users Capacity
  • Two Cards Per User

choose credentials MATRIXChoose Credential as per Convenience

  • Time-Attendance and Access Control with Proximity/Smart Cards
  • Proximity: EM Prox, HID Prox
  • Smart: Mifare and HID iCLASS

convenient communication MATRIXConvenient Communication Options

  • Ethernet
  • RS-485
  • Power over Ethernet (PoE)

perform functions MATRIXPerform Applications using APIs

  • Communication with Third Party Software
  • Communicate using Device API
  • Device and User Configuration, Enrolment, Transfer of Commands and Events

convenient operation MATRIXUser Friendly Operation and Installations

  • Standalone and Network Operation
  • Easy Mounting on a Back Plate
  • Leverage Existing Network Infrastructure
  • Minimum Wiring

INTERFACE DIAGRAM
cosec path dccx
TECHNICAL SPECIFICATIONS
VariantsCOSEC PATH DCCECOSEC PATH DCCMCOSEC PATH DCCI
Credential SupportRFID CardRFID CardRFID Card
Card TypeEM ProxMifare SmartHID iCLASS, HID Prox
User Capacity10,00010,00010,000
Cards Per UserTwoTwoTwo
Events Buffer50,00050,00050,000
RS-485Yes (115.2Kbps)Yes (115.2Kbps)Yes (115.2Kbps)
Battery BackupNoNoNo
EthernetYes (10/100Mbps)Yes (10/100Mbps)Yes (10/100Mbps)
PoEYes (IEEE 802.3 af)Yes (IEEE 802.3 af)Yes (IEEE 802.3 af)
Exit SwitchYesYesYes
Door Status SenseProgrammable NO, NC and SupervisedProgrammable NO, NC and SupervisedProgrammable NO, NC and Supervised
Door Lock RelayForm C and SPDT Relay (Max 1A@30 VDC)Form C and SPDT Relay (Max 1A@30 VDC)Form C and SPDT Relay (Max 1A@30 VDC)
Door Lock PowerInternal 12VDC @ 0.5A or ExternalInternal 12VDC @ 0.5A or ExternalInternal 12VDC @ 0.5A or External
Reader Interface typesRS-232 and Wiegand IN/OUTRS-232 and Wiegand IN/OUTRS-232 and Wiegand IN/OUT
BuzzerYesYesYes
LEDSingle LED (TriColor)Single LED (Tri-Color)Single LED (TriColor)
CPU32Bit Microcontroller32Bit Microcontroller32Bit Microcontroller
Flash Memory512kB Internal Memory + 4MB External Flash512kB Internal Memory + 4MB External Flash512kB Internal Memory + 4MB External Flash
RAM Memory128kB SRAM128kB SRAM128kB SRAM
Input Power12VDC @ 2A12VDC @ 2A12VDC @ 2A
Humidity5% to 85% RH Non- condensing5% to 85% RH Non- condensing5% to 85% RH Non- condensing
Tamper DetectionYesYesYes
IP65VerifiedVerifiedVerified
CertificationCE and BISCE and BISCE and BIS
Dimension (mm)50.5X137X3450.5X137X3450.5X137X34
Weight (kgs)0.180.180.18
Get the COSEC PATH DCCX Access Control System for your organization. For more information fill the following form contact us at 91-9315-4410-53, +91-9315-4410-78WhatsApp 9315441053 or email us at info@ampletrails.com.

read more

COSEC PATH DCFX

cosec path dcfx

APPLICATIONS
Time- attendanceTime AttendanceAccess ControlAccess Control
Visitor managementVisitor Managementcontract workers managementContract Workers Management
KEY FEATURES

superior design MATRIXSuperior Design

  • Compact Design
  • IP65 Rating
  • Tri Colour LED (Allowed, Denied/Alarm and Status)

manage users MATRIXBetter Capacity to Manage Multiple Users and Events

  • Events Storage up to 50,000
  • 9,600 Fingerprint Templates
  • 2,000 Users

CREDENTIALS REQUIREMENT MATRIX
Choose Credential as per Convenience

  • Fingerprint, Proximity and Smart Cards
  • Proximity: EM Prox and HID Prox
  • Smart: Mifare and HID iCLASS

multiple connectivity MATRIX
Convenient Communication Options

  • Ethernet
  • RS-485
  • Power over Ethernet (PoE)

perform functions MATRIX
Perform Applications using APIs

  • Communication with Third Party Software
  • Communicate using Device API
  • Device and User Configuration, Enrolment, Transfer of Commands and Events

convenient operation MATRIX
User Friendly Operation and Installation

  • Standalone and Network Operation
  • Easy Mounting on a Back Plate
  • Leverage Existing Network Infrastructure
  • Minimum Wiring

INTERFACE DIAGRAM

TECHNICAL SPECIFICATIONS COSEC PATH DCFX
VariantsCOSEC PATH DCFECOSEC PATH DCFMCOSEC PATH DCFI
Credential SupportFingerprint and RFID CardFingerprint and RFID CardFingerprint and RFID Card
Template Per UserUp to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode)Up to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode)Up to Ten (Single Template per Finger Mode) or Up to Five (Dual Template per Finger Mode)
Card TypeEM ProxMifare SmartHID iCLASS, HID Prox
Template Storage Capacity9,6009,6009,600
Cards Per UserTwoTwoTwo
Events Buffer50,00050,00050,000
RS-485Yes (115.2Kbps)Yes (115.2Kbps)Yes (115.2Kbps)
Battery BackupNoNoNo
EthernetYes (10/100Mbps)Yes (10/100Mbps)Yes (10/100Mbps)
PoEYes (IEEE 802.3 af)Yes (IEEE 802.3 af)Yes (IEEE 802.3 af)
Exit SwitchYesYesYes
Door Status SenseProgrammable NO, NC and SupervisedProgrammable NO, NC and SupervisedProgrammable NO, NC and Supervised
Door Lock RelayForm C and SPDT Relay (Max 1A@30 VDC)Form C and SPDT Relay (Max 1A@30 VDC)Form C and SPDT Relay (Max 1A@30 VDC)
Door Lock PowerInternal 12VDC @ 0.5A or ExternalInternal 12VDC @ 0.5A or ExternalInternal 12VDC @ 0.5A or External
Reader Interface typesRS-232 and Wiegand IN/OUTRS-232 and Wiegand IN/OUTRS-232 and Wiegand IN/OUT
BuzzerYesYesYes
LEDSingle LED (TriColor )Single LED (Tri-Color )Single LED (Tri-Color )
CPU32Bit Microcontroller32Bit Micro-controller32Bit Micro-controller
Flash Memory512kB Internal Memory + 4MB External Flash512kB Internal Memory + 4MB External Flash512kB Internal Memory + 4MB External Flash
RAM Memory128kB SRAM128kB SRAM128kB SRAM
Input Power12VDC @ 2A12VDC @ 2A12VDC @ 2A
Humidity% to 85% RH Noncondensing% to 85% RH Noncondensing% to 85% RH Noncondensing
Tamper DetectionYesYesYes
IP65VerifiedVerifiedVerified
CertificationCE and BISCE and BISCE and BIS
Dimension (mm)50.5X160X4450.5X160X4450.5X160X44
Weight (kgs)0.270.270.27
Get the COSEC PATH DCFX Access Control System for your organization. For more information fill the following form contact us at 91-9315-4410-53, +91-9315-4410-78WhatsApp 9315441053 or email us at info@ampletrails.com.

read more

COSEC ARC DC100S

cosec arc dc100s

APPLICATIONS
access control
Access Control
KEY FEATURES

better capacity MATRIXBetter Capacity

  • Supports 10,000 Users
  • Storage up to 1,00,000 Events

 modular architecture MATRIXModular Architecture

  • Works as Standalone Access Control Solution
  • Ideal for Network Mode Solution at Multiple Locations

easy integration MATRIX
Easy Integration

  • Seamless Integration with Existing Third Party Wiegand Readers
  • Aux-In and Aux-Out Port to Connect Third Party Devices

INTERFACE DIAGRAM
arc-dc-100s
TECHNICAL SPECIFICATIONS COSEC ARC DC100S
GENERAL
ReadersTwo
DoorOne/Two
Users10,000
Event Buffer1,00,000
Input PowerExternal Power Adapter (12VDC@2A)
CommunicationEthernet (with COSEC PANEL LITE or COSEC application)
CPU32-bit Microcontroller
Flash Memory512kB Internal Flash + 4MB External Flash
RAM Memory128kB SRAM
LEDTwo (Device Status and Network Status)
Reader
ConnectionsDATA0, DATA1, LED0, LED1, BUZZER, Tamper, Power, GND, RS-485A and RS-485B
Power12VDC at max. 150mA per Reader
Reader TypesTwo Reader Ports for Wiegand or Matrix Reader
InterfaceWiegand and RS-485 (for Matrix Reader only)
Max Distance400 meters (on RS-485) and 100meters (on Wiegand)
IN/OUT
Exit Switch PortYes
Door Status SenseProgrammable NO, NC and Supervised
Door Lock RelayRelay SPDT, Form C and Max 5A @ 24VDC
AUX-In PortYes (Single door)/No (Double door)
AUX-Out PortYes (Single door)/No (Double door)
Get the COSEC ARC DC100S Access Control System for your organization. For more information fill the following form contact us at 91-9315-4410-53, +91-9315-4410-78WhatsApp 9315441053 or email us at info@ampletrails.com.

People found us through search:

read more

COSEC ARC DC100P

ARC DC100P

COSEC ARC DC100P

APPLICATIONS
Access Control
Access Control
INTERFACE DIAGRAM

compact design MATRIXCompact Design

  • Supports 10,000 Users
  • Event Storage up to 1,00,000
  • Supports Data and Power on PoE for Readers and Door Locks

modular architecture MATRIXModular Architecture

  • Works as Standalone Access Control Solution
  • Ideal for Network Mode Solution at Multiple Locations

easy integration MATRIXEasy Integration

  • Seamless Integration with Existing Third Party Wiegand Readers
  • Aux-In and Aux-Out Port to Connect Third Party Devices

INTERFACE DIAGRAM
COSEC ARC DC100P MATRIX

TECHNICAL SPECIFICATION COSEC ARC DC100P
GENERAL
ReadersTwo
DoorOne/Two
Users10,000
Event Buffer1,00,000
Input PowerPoE or External Power Adapter (12VDC@2A)
CommunicationEthernet (with COSEC PANEL LITE or COSEC application)
CPU32-bit Microcontroller
Flash Memory512kB Internal Flash + 4MB External Flash
RAM Memory128kB SRAM
LEDTwo (Device Status and Network Status)
Reader
ConnectionsDATA0, DATA1, LED0, LED1, BUZZER, Tamper, Power, GND, RS-485A and RS-485B
Power12VDC at max. 150mA per Reader
Reader TypesTwo Reader Ports for Wiegand or Matrix Reader
InterfaceWiegand and RS-485 (for Matrix Reader only)
Max Distance400 meters (on RS-485) and 100meters (on Wiegand)
IN/OUT
Exit Switch PortYes
Door Status SenseProgrammable NO, NC and Supervised
Door Lock RelayRelay SPDT, Form C and Max 5A @ 24VDC
AUX-In PortYes (Single door)/No (Double door)
AUX-Out PortYes (Single door)/No (Double door)
Get the COSEC ARC DC100P Access Control System for your organization. For more information fill the following form contact us at 91-9315-4410-53,
+91-9315-4410-78 WhatsApp 9315441053 or email us at info@ampletrails.com.

read more

COSEC VEGA CAX

cosec vega cax

APPLICATIONS
Time- attendanceTime-AttendanceAccess ControlAccess ControlVisitor managementVisitor Management
cafeteria managementCafeteria Managementcontract workers managementContract Workers ManagementJob processing & costingJob Processing and Costing
KEY FEATURES
superior design
Excellent Design with Advanced Technology
  • 3.5” TFT Touchscreen LCD
  • Compact Design
  • Pluggable Card Reader Module
  • IP65 Rating
multiple connectivity
Multiple Options for Connectivity
  • RFiD Card and PIN
  • Proximity and Smart Card
  • EM Prox, Mifare and HID iCLASS
communication with server
Communication with the Server
  • Ethernet
  • Power over Ethernet (PoE)
  • Built-in Wi-Fi
  • Mobile Broadband 3G/4G (through USB Dongle)
higher capacity
Higher Capacity for Managing Multiple Users and Events
  • 50,000 Users Capacity
  • Event Storage up to 5,00,000
various interfaces
Different Applications with Multiple Interfaces
  • Door Relay and Door Sense
  • Auxiliary Input and Output Port
  • Exit Reader and Exit Switch
perform applications
Powerful Device APIs to Perform Applications
  • Communication with Third Party Software
  • Integration using Device API
easy operation
Easy Operation and Installation
  • User Friendly GUI
  • Standalone and Network Operation
  • Easy Mounting on Back Plate
  • Leverage Existing Network Infrastructure
  • Minimum Wiring
INTERFACE DIAGRAM
cosec vega cax
VariantsCOSEC VEGA CAX
Credential SupportRFID Card and PIN
Cards Per UserUp to Two
Type of CardEM Prox, Mifare, and HID iCLASS (Card Module is required)
User Capacity50,000
Display3.5″ TFT Display with Capacitive Touch Panel
Communication PortEthernet, Wi-Fi, Mobile Broadband (3G/4G Using USB Dongle)
Built-in PoEYes
Built-in Wi-FiYes
USBOne USB Port (for Data Transfer and Mobile Broadband)
Event Buffer5,00,000
Exit Switch PortYes
Exit ReaderYes
Reader Interface TypesRS-232 and Wiegand
Reader Power OutputInternal 12VDC @ 0.5A or External
Door Status SenseProgrammable NO, NC, Supervised
Door Lock RelayRelay SPDT, Form C, 1A @ 30VDC
Door Lock PowerInternal 12VDC @ 0.5A or External
Aux-InProgrammable NO, NC, Supervised
Aux-OutRelay SPDT, Form C, 1A @ 30VDC
Tamper DetectionYes
Input Power12VDC @ 2A
Operating Temperature0° C to +50°C (32°F to 122°F),
Humidity5% to 95% RH Non-condensing
IP65Verified
STQC CertifiedNo
CertificationCE,FCC PART15B(VOC),BIS,ROHS
Dimensions (mm)91X186X38
Weight (kgs)0.54
Get the COSEC VEGA CAX Access Control System for your organization. For more information fill the following form contact us at 91-9315-4410-53,
+91-9315-4410-78 WhatsApp 9315441053 or email us at info@ampletrails.com.

People found us through search:

read more

Iris Scanner Ayushman Bharat Yojana

Mantra IRIS Scanner MIS100V2

Iris Scanner Ayushman Bharat Yojana
Currently, Aadhaar based Biometric machines are supporting various social welfare schemes rolled out by Government such as Atal Pension Yojana, Pradhan Mantri Gramin Awaas Yojana, Rashtriya Bima Yojana, Janani Suraksha Yojana, Smart Cities mission and many.

Ayushman Bharat Yojana Biometric Machine

Ayushman Bharat Yojana Biometric Machine

Our Aadhaar based Biometric devices are best suitable for flawless implementation and handy utilization for verification of patients by different Hospitals, Dispensaries and Wellness Centres. The device based on leading edge technology utilizes Fingerprint and Iris Scan methodology for identification of the patients. Our devices streamline the identification process of the patients during the claim procedure.

Aadhaar enabled Biometric Solution provides benefits such as:-

  • Eliminates the prolonged Queuing System during the Patients’ visit to Hospitals
  • Easy accessibility of Patients’ information through Aadhaar Number
  • Easy to manage the records of Patients
  • Offers seamless Patients’ verification procedure
  • Simple to utilize
  • Reduces the complexity of Claim procedure



MIS100V2 IRIS SCANNER

MIS100V2 IRIS SCANNER

Iris recognition is an automated method of biometric identification that uses mathematical pattern-recognition. MIS100V2 is an ultra-compact, auto-capture camera module, complete with onboard iris recognition. MIS100V2 OEM module features superior iris matching and iris image quality assessment algorithms to provide good quality images.

Iris Scanner Ayushman Bharat Yojana

Iris Scanner Ayushman Bharat Yojana

About Ayushman Bharat Yojana

The Ayushman Bharat Yojana is a government-sponsored healthcare scheme benefiting the beneficiaries. The Ayushman Bharat Yojana will engage hospitals and wellness centers across the Nation that will play a critical role in paying attention towards healthcare of an individual. Under Ayushman Bharat Yojana, a beneficiary requires to visit the Hospital or Dispensary preferably with Aadhaar card or any other Government ID for the verification of an individual.

Iris Scanner Ayushman Bharat Yojana Price

Iris Scanner Ayushman Bharat Yojana Price

Single Iris Scanner – Mantra MIS 100 V2 USB Biometric Device

Beneficiary Identification System Process Flow

The Ayushman Bharat Yojana is the biggest government sponsored health care scheme in India that aims to serve the poor. The scheme helps in providing the health care benefits to needy people while the Beneficiary Identification System (BIS) adopted in Hospitals aids in streamlining the whole process. Additionally, the system assists in verifying an individual and their families. However, for a well organized Identification process, the cutting-edge Biometrics technology is desirable. Flowchart displayed above will give a broader view of how the BIS work.

Beneficiary Identification System Process Flow

Beneficiary Identification System Process Flow

Mantra IRIS Scanner MIS100V2

Mantra IRIS Scanner MIS100V2

Ayushman Bharat Yojana Process
Best IRIS (Eye) Scanner of its class
Features of Mantra MIS100V2 IRIS SCANNER

Applications of Mantra MIS100V2 IRIS SCANNER
PC Computers / Network Security, AFIS, AEBAS, Time and attendance, Health and Medical, Skill Development, Smart card application, UIDAI, NREGA, Public applications, Jeevan Praman and PDS.

Mantra IRIS Scanner MIS100V2 Brochure



















AB PM-JAY Health care Transaction Work flow Summary



AADHAAR BIOMETRIC DEVICES FOR AYUSHMAN BHARAT PROGRAM

AADHAAR BIOMETRIC DEVICES
FOR AYUSHMAN BHARAT PROGRAM

The Ayushman Bharat Yojana will engage hospitals and wellness centres across the Nation that will play a critical role in paying attention to health care of poor people. Under Ayushman Bharat Yojana, a beneficiary needs to visit the Hospital or Dispensary with preferably Aadhaar card or any other Government ID for the verification of an individual. The scheme aims at providing health assurance to 10 Crore families.

To buy single Iris scanner call us at 9315441053,78

Email us at info@ampletrails.com or call us at 9818390836 for pricing of this machine.

People found us through search:

read more

Mantra MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE

MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE
MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE


The MFSTAB 4G Fingerprint Biometric machine is all-in-one, affordable, WiFi enabled terminal. It can be used for various applications such as Time Attendance, Access Control, Workflow Management, Canteen Management, Visitor Management, Worker Management etc.

MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE

MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE

 MFSTAB 4G Fingerprint Biometric machine This innovative Biometric clock will dramatically improve your ability to monitor your workforce movements during their working patterns and with enhanced features that give you a better time and management reporting.
Mantra_MFSTAB-4G Brochure Download
The MFSTAB 4G Fingerprint Biometric machine is suitable for both basic to moderately complex time and attendance requirements. The 7″ Touchscreen offers a wide range of possibilities, starting from the classical Time recording App to a complex Factory Data Collection App or a high-security solution with access queries supported by a comparison of live images with stored images or audio-visual communication to a Service Command Center, e.g. for Data centers. Everything is possible.

Features of MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE

MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE

MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE

  • The contemporary aesthetic that blends perfectly with modern architecture
  • Support various RFID readers like proximity reader, Mifare reader
  • Compatible with state of the art TimeTrak, BioPay software.
  • Inbuilt battery backup to ensure 99.9% uptime
  • 1:1 or 1: N Fingerprint Matching functions
  • Support STQC/Aadhaar Certified fingerprint reader
  • Data retention in case of power failure, no loss of data.
  • Online/offline software makes individual operation easy to manage.
  • Wifi means cable-less installations.
  • Dual SIM Card Support
  • 4G Enabled

Applications of MFSTAB 4G FINGERPRINT BIOMETRIC MACHINE

Mantra Aadhar Biometric Machine MFS Tab

Mantra Aadhar Biometric Machine MFS Tab

  • Time Attendance
  • Visitor Management
  • Aadhaar Authentication
  • Access Control
  • Canteen Management
  • Financial Inclusion/eKYC
  • Worker Management
Mantra Aadhar Biometric Machine MFS Tab



Mantra aadhaar enabled biometric attendance system

Mantra is a leading STQC certified manufacturer of the key Biometric product for Aadhaar project in India. We provide Fingerprint scanner & Iris scanner for Aadhaar enrollment center.

TALK TO AMPLETRAILS PROFESSIONAL FOR BULK ORDER. Call Now at 9315441078/53
Every client has unique requirement. Working together we’ll discover the right solution which fits in your budget to reach desire goal.

Mantra Aadhaar Enabled Biometric Attendance System

Mantra Aadhar enabled Biometric Machine MFS Tab dealer distributor

Being Authorize Mantra dealer and distributor in India we supply Aadhar enabled MantraBiometric Machine MFS Tab

For more information contact us at 09818390836, 09315441078 or email us at info@ampletrails.com.

People found us through search:

read more

i-Shield range of Video door phones from Honeywell

i-Shield range of Video door phones from Honeywell

i-Shield range of Video door phones from Honeywell

i-Shield range of Video door phones from Honeywell

i-Shield range of Video door phones from Honeywell

Be Safe. Be Secure Always.

Introducing Honeywell i-Shield A7SD Video Door Phone. So you always know who is at your door.

The color video door phone can be used to monitor, call, intercom and unlock. It is a product that is suitable for villa, single house, apartments, office, giving you the combined benefit of security and convenience.

Gives you an added layer of security with password unlock functionality.

Stronger security with a wider coverage area outside your door with 120 degree wide angle camera

Superior experience & aesthetics with touch buttons and ultra-thin design.

Keeps a track even when you are not at home, with video recording option

No compromise on safety, raises an alarm in case of a theft attempt on outdoor camera unit.

Loud enough to ensure nothing is left to change upto 60db for call and upto 70dB for the alarm.

Honeywell Video Door Phone

Honeywell Video Door Phone

 Ghar Me honeywell to life very well To know more call us at 9315441053 or email at info@ampletrails.com

For more information about biometric face and RFID Time Attendance and Access, Control Machine call us now at 9315441078 WhatsApp 9315441053, 9818390836. Email us regarding your face Attendance Machine requirements at info@ampletrails.com.

read more
WhatsApp chat
