COSEC PATH DCFE

Sale!

COSEC PATH DCFE

16,942.00

Fingerprint and EM Proximity Card based Door Controller

  • BLE, RFID and Fingerprint as Credentials
  • Access Control and Time-Attendance
  • IP65 Rating
  • 5,00,000 Events and 25,000 (1:N) and 1,00,000 (1:1) Fingerprint Template Storage
  • Wi-Fi, BLE, Ethernet, RS-485/RS-232, POE
  • Built-In Door Lock Port, Door Sense Port, Exit Reader Port, Exit Switch Port, RS-485 and Ethernet
  • Tri-color LED and Buzzer
  • 12VDC Power Supply through Adaptor or Battery Backup

19 in stock

Description

Matrix COSEC path DCFE price, matrix standalone access control system.

  • Fingerprint and EM Prox Card based Single Door Access Controller
  • • Finger, EM Prox Card and Mobile Phone(BLE)
  • • Ethernet, PoE, Wi-Fi and BLE
  • • Door Lock, Door Sense, Exit Reader, Exit Switch, RS-485/RS-232, Wiegand IN/OUT
  • • IP65 Rated Controller with Built-in Readers
  • • 50,000 Users, 25,000 (1:N) and 1,00,000 (1:1) Fingerprint Templates and 5,00,000 Events
  • • Tri-color LED and Buzzer
  • • 12VDC Power Supply through Adaptor or Battery Backup

Features of COSEC PATH DCFE

COSEC PATH series – biometric door controllers, are the brain of the system, which allows only authorized users to enter the premises and register their entry and exit time.

matrix cosec path dcfe

matrix cosec path dcfe

Matrix COSEC PATH is a series of compact door controllers engineered to endure extreme weather conditions. Having a dual advantage of advanced security, these controllers support credentials such as fingerprint and RFID cards. With its versatile interfaces and PoE connectivity, these compact yet efficient door controllers are best suited for indoor and outdoor applications. Its advanced features like Wi-Fi & Bluetooth connectivity, PoE, IP65, and multi-credentials support fingerprint and RFID card options, it fulfills the requirements of many organizations. With a storage capacity of 50,000 events and 9,600 fingerprints, it assures reliable and long term consistent performance.

Having IP65 design makes it a foolproof solution for Time-Attendance, Access Control, Cafeteria Management and other applications.

COSEC VARIANTS

  • COSEC PATH DCFx
  • COSEC PATH DCCx

Cosec Path Series



COSEC_Technical_Specification_COSEC_PATH_DCFE_V2



GENERAL
Credential Support BLE, Fingerprint and RFID Card
IP Rating Yes (IP65 Design)
RF Option Proximity (EM Prox – 125KHz)
CAPACITY
Max. Users 50,000
Max. Template Storage SFM 6030: 25,000 (1:N) And 100,000 ( 1:1)
Event Buffer 5,00,000
COMMUNICATION
Wi-Fi Bluetooth Yes (IEEE 802.11 b/g/n) Yes (BLE 4.0)
Ethernet Yes
RS-232 Yes
RS-485 Yes
Wiegand Wiegand IN/OUT Available
USB No
INTERFACE
Exit Switch Yes
Door Status Sense Yes (2 State)
Door Lock Relay Yes
Reader Power Output Internal 12 VDC @ 0.250 Amp
Aux-In NO
Aux-Out NO
Reader Interface Types RS-232 & Wiegand IN/OUT


HARDWARE

CPU Cortex A8 800 MHz
Flash memory 512 MB
RAM memory 512 MB
LED Single Tri-Color LED
Buzzer Yes
Operating Temperature 0°C to +50°C (32°F to 122°F)
Humidity 5% to 95% RH Non – Condensing
Tamper Detection Yes
Power 12V DC @ 2A
Power to Door Lock Yes



Internal 12 VDC @ 0.5 Amp

Dimensions (W x H x D) 50.5mm x 160mm x 44mm (1.98″x6.29″x1.73″)
Battery Backup Through COSEC PATH BBU or COSEC PSBB12V
Weight 0.27 Kgs (0.59 lbs.)
SENSOR
Sensor Name Suprema Sensor
Sensor Technology Optical
Encryption 256-bit AES
Water-proof Yes
False Acceptance Ratio (FAR) 0.001%
False Rejection Ratio (FRR) 0.01%
Resolution (dpi) 500 dpi
Sensing Area 16.00mm x 19.00mm
Template Size 384 Bytes
Image Size (Pixel) 272mm x 320mm
COMPATBILITY
System Integration API for Software Integration
Operational Modes Direct Door with COSEC CENTRA Server Panel Door with COSEC PANEL LITE V2


APPLICATIONS

  • Access Control
  • Time-Attendance
  • Contract Workers Management
  • Job Processing and Costing

TECHNICAL SPECIFICATIONS

If you want to get more details please fill the form below. Our experts will contact you to give face attendance and various other solutions as per your requirements. Call us at 9315441078 or email us at info@ampletrails.com

Matrix COSEC PATH is a series of door controllers engineered to endure extreme weather conditions. These controllers offer multiple credentials such as mobile using BLE, RFID cards and fingerprint. With its versatile interfaces and PoE connectivity, these compact yet efficient door controllers are best suited for indoor and outdoor applications.

Key Features:

Higher Capacity
5,00,000 Events
50,000 Users
25,000 (1:N) AND 100,000 (1:1) Fingerprint Templates

Multiple Credentials
Mobile Using Bluetooth
RFID Cards
Fingerprint

Convenient Communication Options
Wi-Fi
Ethernet
RS-232 and RS-485
Wiegand
Bluetooth

Superior Designs
Compact
IP65 Rating
Tri-colour LED (Allowed, Denied/Alarm and Status)

Built-in Reader
Easy Installation
Less Wiring
Save Separate Hardware Cost

Multiple Applications
Time-Attendance
Access Control
Visitor Management
