Flap Barrier

Flap Barrier FB-TL3000

Flap Barrier FB-TL3000



Features
Size :1410x340x1005mm
Unlock time : 0.2s
Pass rate : 35 person/min
Pass width : ≤600mm
Flap barrier FB-TL-3000

Flap Barrier Fingerprint FB-TL3000

Flap Barrier Fingerprint FB-TL3000

Flap Barrier : FB-TL-3000
Size 1410x340x1005mm
Unlock time 0.2s
Pass rate 35 person/min
Pass width ≤600mm
Input  100V~240V
Motor voltage 24v
Environment -25~+70
Power consumption 35w
Input Dry Contact
  • anti-clipping function, photocell anti-clipping and mechanical anti-clipping
  • Auto re-set fuction,if no passing during identified card-reading time ,the system will reset automatically the passengers are prohibited to pass until their second identified reading
  • The barrier can be set to delay closing in 1~60s after valid card-reading



IN GENERAL
  •  Use IC cards,ID cards, Bar code or magnetic cards as automatic identification system and achieve access, attendance fees or function
  •  A direction indicator ,showed that pedestrian access to the current status of,and guide pedestrians correct and smooth passage
  •   Display has been in use for statistics and numbers
  •   With voice and strobe light alerts
  •   A combination of infrared sensors and police anti-illegal entry into pedestrian access, the protection of pedestrians smooth and the prevention of the channel following
OPERATING MOOES
  • Single passage in the set direction
  • Bi-directional single passage
  • Free passage in the set direction
  •  Always free or locked
MATERIALS
  •  Housing: Made in metal sheet and painted with 20/10,or in stainless steel ALSL 304 o AISI316
  • Barrier swings-Plastic plate,thoughened glass, stainless steel frame
  • Lid(optional)—stainless steel or artificial stone(black/brown)
COLORS & FINISHES
  • High quality power coating plus lacquered finish
  • Dark grey color high quality power coating plus lacquered finish
  • Sandpaper powder coating with pearl mica effect
Mechanism
  • Heavy-duty design for 24 hours continuous application
  • Heavy duty pull type
  • Indoor or outdoor application
  • High durability with industrial parts
  • All the running is quiet without any noise and shock
Communication
  • Dry contact relay with 12 volt or 24 volt pulse
  • RS485 or TCP-IP communication with computer
  • High durability with industrial parts
  • All running is quiet without any noise & shock
Motor
  • Three million times or above test for motor
Flap Barrier FB-TL-119-219

Flap Barrier FB-TL-119-219

For more information about Biometric Attendance System, biometric fingerprint and RFID Time Attendance & Access Control Machine call us now at 9034757673, 9818390836.  You can email your requirements at info@ampletrails.com and contact us for essl biometric attendance machine price in India.
