COSEC PATH RDFE Matrix

COSEC PATH RDFE Matrix

Compact Door Controller for Access Control and Time-Attendance

Biometric door access control system

Door access control system for office

Access Control and Time Attendance is the basic necessity of the Corporate world. With the increasing need of the world for complete security, biometrics became the foundation to laying down a full-fledged secure infrastructure.

Key Features:

  • Multi- Credential support – RFID card, BLE, and Fingerprint
  • Multi-connectivity support – Bluetooth, Wi-Fi, POE, and Ethernet
  • High storage capacity – 50,000 users and 5,00,000 templates
  • Easy third-party communication with built-in API

Matrix brings to you, the next-gen “IP to Door” door controller – COSEC PATH, a perfect blend of sleek and smart with multiple modern credentials support. With a top-notch secure communication channel with a server, it acts as the ideal component for any mission critical or simple access control applications for the organizations.

Fingerprint and EM Prox Card based Reader COSEC PATH RDFE Matrix

Fingerprint and EM Prox Card-based Reader

  • Fingerprint and EM Prox Card based Reader
  • Optical Fingerprint and EM Proximity Card based Reader
  • RS-232/RS-485 Interface
  • IP65 Rating
  • Tamper Detection
  • Tri-color LED and Buzzer
  • 12VDC Power Supply through Adaptor or Battery Backup
  • Compatible with any COSEC Door Controllers (Except FOT Variants)
COSEC PATH RDFX is a series of compact readers having advanced features like IP65 and compact design, which fulfills the access control requirements of organizations. It provides credential support for Fingerprint and RFID card.

  • Superior Design
  • Compact Design
  • IP65 Rating
  • Tri-color LED (Allowed, Denied/Alarm and Status)
  • Choose Credential as per Convenience
  • Fingerprint, Proximity, and Smart Cards
  • Proximity: EM Prox and HID Prox
  • Smart: MIFARE® and HID iCLASS
  • Convenient Communication Options
  • RS-232 and RS-485
  • Fetch Power from Device
  • User-Friendly Operation and Installation
  • Standalone and Network Operation
  • Easy Mounting on a Back Plate
  • Leverage Existing Network Infrastructure
  • Minimum Wiring

Fingerprint and EM Prox Card-based Reader

Fingerprint Exit Reader, Exit Reader, Matrix Fingerprint reader

  • Optical Fingerprint and EM Proximity Card based Reader
  • RS-232/RS-485 Interface
  • IP65 Rating
  • Tamper Detection
  • Compatible with any COSEC Door Controllers (Except COSEC DOOR FOT)
  • Tri-Color LED and Buzzer
  • 12VDC Power Supply through Adaptor or Battery Backup

Matrix biometric access control system

Fingerprint and EM Proximity Card based Door Controller

  • • BLE, RFID, and Fingerprint as Credentials
  • • Access Control and Time-Attendance
  • • IP65 Rating
  • • 5,00,000 Events and 25,000 (1:N) and 1,00,000 (1:1) Fingerprint Template Storage
  • • Wi-Fi, BLE, Ethernet, RS-485/RS-232, POE
  • • Built-In Door Lock Port, Door Sense Port, Exit Reader Port, Exit Switch Port, RS-485 and Ethernet Interfaces
  • • Tri-Color LED and Buzzer
Variants COSEC PATH RDFE COSEC PATH RDFM COSEC PATH RDFI
Credential Support Fingerprint and RFID Card Fingerprint and RFID Card Fingerprint and RFID Card
Sensor Optical Optical Optical
Template storage capacity 9,600 9,600 9,600
Type of Card EM Prox MIFARE Classic® Smart HID iCLASS, HID Prox
Communication RS-485 and RS-232 RS-485 and RS- 232 RS-485 and RS- 232
Buzzer Yes Yes Yes
LED Single LED (Tri Color) Single LED (Tri Color) Single LED (Tri Color)
Input Power 12 VDC @ 0.1A 12 VDC @ 0.1A 12 VDC @ 0.1A
Humidity 5% to 85% RH Non-condensing 5% to 85% RH Non-condensing 5% to 85% RH Non-condensing
Operating Temperature 0°C to + 50°C (32°F to 122°F) 0°C to + 50°C (32°F to 122°F) 0°C to + 50°C (32°F to 122°F)
Tamper Detection Yes Yes Yes
IP65 Verified Verified Verified
Dimension (mm) 50.5X160X44 50.5X160X44 50.5X160X44
Weight (kgs) 0.18 0.18 0.18

If you want to get more details please fill the form below. Our experts will contact you to give face attendance and various other solutions as per your requirements. Call us at 9315441078 or email us at info@ampletrails.com

MIFARE and MIFARE Classic are trademarks of NXP B.V.
