Baggage Scanner

Baggage Scanners Suppliers in India

Baggage Scanner

eSSL Baggage Scanner

Baggage X-Ray Scanning Machine Suppliers eSSL-X_5030C

Baggage X-Ray Scanning Machine Suppliers eSSL-X_5030C

Dual Energy X-ray Inspection System

Baggage Scanner

Baggage Scanner

 Specifications of Baggage Scanner
  • Tunnel Size : W660mm × H510mm | Speed : 0.20 m/s
  • Height of Transmission Belt : 1300 mm
  • Maximum Load : 180 kg (Adequate distribution)
  • Wire Resolution : 40 AWG (0.0787mm metal wire)
  • Space Dimension : Horizontal 1.0mm \ Vertical 2.0mm
  • Penetrate Dimension : 34 AWG
  • Penetration : 38mm Steel board | Monitor : 17 inch LED
  • System Function : High density alarm, Explosive/Drug auxiliary detect,
  • TIP, Luggage counter, System running timer, X-ray emitting timer,
  • Training, 64 times continuous zoom in
  • Film Safety : ASA/ISO1600 standard of film safety
 X-ray System Baggage Scanner

Baggage Scanners for Hotels. We provide baggage scanners for Hotels which can be used to scan big luggage carried by the guest staying in hotels. Baggage Scanning Machine manufacturer in India are not there.  All are imported from countries like China.

  • Tube Voltage : 150 Kv
  • Cooling : Seal oil cooling / 100%
  • Single Inspection Dosage Rate : 1.0  Gy
  • Radiation Leak Dosage : 0.1  Gy/h
  • (5cm from the surface)
 Installation Specification of Baggage Scanner
  • Package Size : L2200mm × W1135mm × H1515mm
  • Console Desk Size : L830mm × W800mm × H1330mm
  • Package Weight : 680KG+105KG (Console desk)
  • Power Consumption : 1 kVA
  • Noise : 53.8 dB(A)

Single Energy X-ray Inspection System

Single Energy X-ray Inspection System Baggage Scanner

Single Energy X-ray Inspection System Baggage Scanner

  • Tunnel Size : 507mm (Width) * 305mm (Height)
  • Speed : 0.20m/s
  • Height of Transmission Belt : 1000mm
  • Maximum Load : 120kg (Adequate distribution)
  • Wire Resolution : 34AWG (0.16mm metal wire)
  • Space Definition : Horizontal 1.0mm Vertical 2.0mm
  • Penetrate Definition : 32AWG
  • Penetration : 8mm Steel board
  • Monitor : 17inch LED
  • System Function : High density alarm, TIP, Luggage counter,
  • System running timer, X-ray emitting timer, System maintainance,
  • Training, 64 times continuous zoom in
  • Optional Function : Video surveillance system, Bidirection scan,
  • Electrical weighing system, Energy saving mode, Ultrasonic rat repellent
  • Flim Safety : ASA/ISO1600 standard of flim safety

Email us at info@ampletrails.com or call us at 9818390836 for pricing and installation of this machine.
