Wireless TVS Bar Code Scanner

• Scan rate of 330 mm
• CCD/C-MOS
• Proprietary Ultra Scan Decoding Technology
• Durable and strong design
• Wireless Cradle

Wireless TVS Bar Code Scanner

The BS-C 103 Platina BT Wireless Gun Type Hand Held Scanner The BS-C 103 Platina provides walk-around freedom – its wireless connection ability enables it to communicate to laptops and bar code printers up to 100 m work range. This highly reliable scanner which eliminates hazardous cables is ideal for daily retail industry, office environment as well as industrial sectors – and is the ultimate for users requiring competence, durability and convenience. Email us at in**@am*********.com or call us at 9315441078 WhatsApp 9315441053, 9034757673 for pricing.  1 Year Carry in warranty Wireless scanner

Transportation and Logistics Wireless Bar Code Scanner

• Proprietary Ultrascan decoding technology
• 32-bit microprocessor unit
• Rugged Gun Type design for tough working conditions and
rough operations
• Flexible communication options
• Wireless freedom at 100M/75M working range
• Smart charging to prolong battery life

Warehouse Wireless Bar Code Scanner

Specifications
Operational
Light Source: 617 nm visible red LED
Optical System Linear CCD array
Image Sensor: 2500 pixels CCD
Depth of Field : 20 – 320 mm (UPC/EAN 100%, PCS=90%)
Scan Angle: 42°
Pitch/Roll/Skew : ±75° / ±25° / ±60°
Angle
Scan Rate: 330 scans per second
Minimum Bar Width : 0.07 mm (3 mil) (Code 39, PCS = 90%)
Print Contrast : Min. 20 % @ UPC/EAN 100%
Indicator (LED) : Beeper and LED; optional vibrator
Programmable : Beeper tone & volume
Operation
System Interfaces: Keyboard, RS-232, HID USB, USB Virtual
COM, wand, OPOS, JPOS
Physical Dimensions
Dimension : 147.0 × 62.0 × 114.5 mm (device only)
: 176.4 × 101.6 × 133.6 mm (with cradle)
Weight: 210 g (with battery) 500 g (with cradle)
Interface Cable: Field-replaceable, standard 3M straight

Point of Sale Wireless Bar Code Scanner

Power
Input Voltage : 5 VDC ±10%
Battery : 3.7V, 2500 mAH, Li-ion Battery
Operating Current : Charging:700(externalpower);
Non-charging:70 mA
Recharging Time : Approx. 4.5 hours via cradle;
6 hours via USB cable
Number of Scan : Over 150,000 scans at 1 scan per second
per full charge
Battery Life : 40 hours per full charge
Radio Communication
Frequency : 2.4 – 2.48 GHz(ISM Band)
Radio Interface : Cradle Host; SPP Master; HID; Slave
Working Range : Up to 100M /75M with communication
cradle(depends on operating environment)
ARIB STD-T66(Japan);NCC(Taiwan)
Regulatory
EMC : CE & FCC DOC compliance, VCCI, BSMI
Safety : IEC 62471 Exempt
Radio : FCC Part 15C; CE EN 300 328;
ARIB STD-T66(Japan);NCC(Taiwan)
Environmental – Operating Conditions
Operating : 0°C – 50°C (32°F – 122°F)
Temperature
Storage : -20°C – 60°C (-4°F – 140°F)
Temperature
Humidity : 5% – 95% RH (non-condensing)
Light Level : 0-100,000 Lux(fluorescence)
Drop Durability : Designed to withstand 1.5M drops
Environmental : IP 41

Document Tracking Wireless Bar Code Scanner

Sealing Decoding Capability
1D Barcode : UPC/EAN/JAN, UPC-A & UPC-E, EAN-8
& EAN-13, JAN-8 & JAN-13, ISBN/ISSN,
Code 39, Codabar, Code 128 & EAN 128,
Code 93, ITF, Addendum 2 of 5, IATA
Code, MSI/Plessy, China Postal Code,
Code 32, Industrial 2 of 5, Standard 2 of 5,
DTF, JAP, Code 11, RSS 14, RSS
Limited, RSS Expanded,Telepen
Warranty : 1 Year
